Product Details:
|
| Application: | Quarry And Mining, Limestone Crusher | Condition: | Grey, White |
|---|---|---|---|
| Weight: | 21t | Dimension(l*w*h): | 3096×3273×2667mm |
| Warranty: | 1 Year | Type: | Impact Crusher |
| Motor Type: | AC Motor | Capacity(t/h): | 150-250 |
| After-sales Service Provided: | Engineers Available To Service Machinery Overseas,commissioning And Training,Video Technical Support | Certification: | CE&ISO |
| Color: | Customizable,Iron Grey,yellow,White,blue | Spare Parts Supply: | Lifelong Time |
| The Machines Classification: | Building Stone Production Line,sand Making Machine,small Stone Impact Crusher | Power(Kw): | 200 |
| Max Feeding Size: | 350 Mm | Installation: | Engineer Guide,Engineers Available To Service Machi |
| Keyword: | Road Construction Machine Impact Crusher | Product Name: | Hot-selling Impact Crusher Price For Barite,PF Impact Crusher |
| After Sale Service: | Life-long Service | ||
| High Light: | Impact Stone Crusher Machine 200Kw,Impact Stone Crusher Machine PF1315,Horizontal Impact Crusher |
||
Impact crusher boasts cubic shape without tension and cracks. It can crush stone smaller than 500mm with compression strength lower than 350MPA, such as granite, limestone, concrete, etc.
Impact crusher is widely used in all kinds of ore crushing, railway, highway, energy, cement, chemical industry, construction, etc. The output size can be adjusted.
Impact crusher crushes material by striking energy. When it works, the motor drives the rotor to rotate at a high speed, on which the blow bar is installed. As soon as the material gets into the affecting area of the blow bar, they will be stroke by the blow bar and be thrown to the impact devices around the rotor. The high speed forces the material to rebound from the impact liner to the area where the blow bar effects until they have been crushed to the required size. The clearance between the impact racks and the rotor can be adjusted to change the size and shape of the end products.
Impact Crusher technology specification :
| Model | Rotor Spec (mm) | Feed opening size (mm) | Max Feed edge(mm) | Capacity (t/h) | Motor Power(kw) | Weight(t) | Overall Dimension(L*W*H)mm |
| PF-1007 | 1000*700 | 400*730 | 300 | 30-50 | 37-55 | 9.5 | 2400×1558×2660 |
| PF-1010 | 1000*1050 | 400*1080 | 350 | 50-80 | 55-75 | 12.2 | 2400×2250×2620 |
| PF-1210 | 1250*1050 | 400*1080 | 350 | 70-120 | 110-132 | 14.9 | 2690×2338×2890 |
| PF-1214 | 1250*1400 | 400*1430 | 350 | 110-180 | 132-160 | 18.6 | 2690×2688×2890 |
| PF-1315 | 1320*1500 | 860*1520 | 500 | 160-250 | 180-250 | 19.3 | 3096×3273×2667 |
| PF-1320 | 1320*2000 | 860*2030 | 500 | 160-350 | 300-375 | 28 | 3096×3560×3185 |
| PF-1520 | 1500*2000 | 1315*2040 | 700 | 300-500 | 400-450 | 42.8 | 3890×3560×3220 |
