Hammer Crusher/Stone Crusher/Sand maker/Quarry Crusher
Hammer crusher
PC series of hammer crusher is widely used in metallurgy, mine, chemical, cement, coal, construction, sand making, refractory materials and ceramic industry. It is used in secondary or tertiary crushing, it is mainly suitable for crushing ores with compressive strength not exceeding 320MPa.
Features of Hammer Crusher
1. Inlet large, high crushing chamber adapted material hardness, block degree, the product
powder less
2. Materials vacant, broken power consumption
3. New hammer, impact force
4. Hammer shaft mounted adjustable, hammer, long life
5. Grid size is adjustable, controllable particle size, particle shape is good
6. Chassis can be flipped, maintenance more convenient
7. Square shank bolts, impact resistance, wear and tear
8. Compact, machine rigidity
9. Fight structure, handling, easy to install
10. The machine shocks, counter, strike (rock stone) fragmentation functions in a high production efficiency, mechanical abrasion is small, the overall efficiency significantly, widely used in artificial sand
Product Parameters
| Model |
Rotor speed
(r/min) |
Feeding size
(mm) |
Discharging size
(mm) |
Capacity
(t/h) |
Power
(Kw) |
Weight
(t) |
| PC400×300 |
1200 |
≤80 |
≤10 |
3-10 |
11 |
0.7 |
| PC600×400 |
1000 |
≤110 |
≤15 |
10-15 |
22 |
1.5 |
| PC800×600 |
980 |
≤120 |
≤15 |
20-25 |
55 |
3.7 |
| PC1000×800 |
980 |
≤200 |
≤45 |
34-54 |
110 |
6.9 |
| PC1000×1000 |
1000 |
≤200 |
≤15 |
40-60 |
132 |
8.5 |
| PC1200×1000 |
745 |
≤200 |
≤25 |
75-150 |
160 |
12.5 |
| PC1200×1200 |
745 |
≤200 |
≤20 |
80-160 |
185 |
14.3 |
| PC1400×1400 |
750 |
≤250 |
≤20 |
120-170 |
280 |
17.2 |
| PC1600×1600 |
500 |
≤350 |
≤20 |
220-290 |
500 |
32.4 |
| PCH600×400 |
970 |
≤200 |
≤30 |
22-33 |
15 |
1.7 |
| PCH600×600 |
980 |
≤200 |
≤30 |
30-60 |
30 |
2.4 |
| PCH800×800 |
825 |
≤300 |
≤30 |
75-105 |
45 |
4.8 |
| PCH1000×1000 |
740 |
≤300 |
≤30 |
90-150 |
90 |
7.5 |
hot selling impact hammer crusher miller price from china Runwell is mainly used to crush kinds of mining stones primarily, and the largest compression resistance of the material to be crushed is 320Mpa. The jaw crusher is widely used in Mining, metall-urgical industry, building material, highway, railway, and chemical industry.
Product Parameters
