Round Ultrasonic Sand Vibrating Screening Machine 18.5Kw 3YK1848 With Mn Steel Net

Large Image : Round Ultrasonic Sand Vibrating Screening Machine 18.5Kw 3YK1848 With Mn Steel Net

Product Details:

Place of Origin:	Shanghai, China
Brand Name:	RUNWELL
Certification:	CE,ISO certificates
Model Number:	3YK1848 vibrating screen

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	USD 20000-40000
Packaging Details:	Container, Nude Packs, in Bulk; Export Packing Standard
Delivery Time:	10-20 working days
Payment Terms:	T/T, Western Union, L/C, MoneyGram
Supply Ability:	50 sets per month

Contact Now

Round Ultrasonic Sand Vibrating Screening Machine 18.5Kw 3YK1848 With Mn Steel Net

Description

Application:	Ore,Mining, And Quarry Plant	Warranty:	1 Year Time From The Production Time
Voltage:	380V,440V With 50Hz Or 60Hz	Max. Feed Sizes:	120mm
Power(Kw):	18.5Kw	Condition:	New Machine
Capacity:	50-250 TPH	Dimension(lwh):	Different Models, The Sizes Are Different
Type:	Vibrating Screen	After-sales Service Provided:	Video Technical Support From Our Engineers
Product Name:	China Rotary Sand Vibrator Screen In High Quality Manufacture	Color:	Iron Grey,customized,black, Or As Per Customer's Demand
Material:	Carbon Steel, Mn Steel Net	Name:	Round Flour Sieving Machine Ultrasonic Vibrating Screen
Layer:	3 Layers	Usage:	Screening,Ore Sand,separation, Reducing The Earth
Highlight:	Sand Vibrating Screening Machine 18.5Kw , Sand Vibrating Screening Machine 3YK1848 , Ultrasonic Vibrating Screen

Sand Screen Separator Sand Vibrating Screening Machine,vibrating rock screen manufacturer,round vibrating screen

Product Description

The moving road of this screen is similar as a circle, so it is called Circular Vibrating Screen. Circular Vibrating Screen is of multilayer and high efficiency. The eccentric shaft vibration exciter and eccentric block helps to adjust amplitude. This kind of screen is of long screening stream line and more sieving specifications. So it is widely used for grading in the industries of quarry, building material, transportation, energy, chemical industry, etc.

Round Ultrasonic Sand Vibrating Screening Machine 18.5Kw 3YK1848 With Mn Steel Net 0

Working Principle

Circular vibrating screen uses common motor that makes the screen do circular movement along the direction of exciting force to sieve the materials.Circular vibrating screen is widely used used for classification in the quarry, building materials, transportation, energy, chemical industry and so on.

Round Ultrasonic Sand Vibrating Screening Machine 18.5Kw 3YK1848 With Mn Steel Net 1

Features

1. It uses eccentric block to produce strong exciting force.
2. The crossbeam and the main body of the screen are connected with high-strength screw bolts, so it has the features of simple structure and easy/convenient maintenance.
3. It adopts tire clutch with flexible connection and stable running.
4. It adopts the structure of small amplitude, high frequency and large obliquity to make the screen have the advantages of high efficiency, large capacity, long durability, low consumption and noise.

Specification

►SPECIFICATIONS

Model	Screen Size(mm)	Layers	Screen Mesh (mm)	Max Feed Size(mm)	Capacity (t/h)	Power (Kw)	Vibrating Frequency(r/min)	Double Swing (mm)
2YK1237	3700*1200	2	3-80	100	10-80	11	750-950	5-9
3YK1237	3700*1200	3	3-80	100	10-80	11	750-950	5-9
2YK1548	4800*1500	2	3-80	100	30-200	15	750-950	5-9
3YK1548	4800*1500	3	3-80	100	30-200	15	750-950	5-9
2YK1848	4800*1800	2	3-80	100	50-250	18.5	750-950	5-9
3YK1848	4800*1800	3	3-80	100	50-250	18.5	750-950	5-9
2YK1860	6000*1800	2	3-80	100	60-300	22	750-950	5-9
3YK1860	6000*1800	3	3-80	100	60-300	22	750-950	5-9
4YK1860	6000-1800	4	3-80	100	60-300	30	750-950	5-9
2YK2160	6000*2100	2	3-80	100	80-400	22	700-900	5-9
3YK2160	6000*2100	3	3-80	100	80-400	30	700-900	5-9
4YK2160	6000*2100	4	3-80	100	80-400	30	700-900	5-9
2YK2460	6000*2400	2	5-80	100	100-500	30	700-900	5-9
3YK2460	6000*2400	3	5-80	100	100-500	37	700-900	5-9
4YK2460	6000*2400	4	5-80	100	100-500	37	700-900	5-9

China Supply Good Quality 2/3/4YK Series Gold Mining Machine Vibrating Screen

Products Description

The vibration screen is a multi-layer, high-efficiency new type vibrating screen designed specifically for quarry screening

stones. Widely used in mining, coal, smelting, building materials, refractories, light industry, chemical and other industries of product classification.

Performance Features

① The material sieve line length is long, and the screening specifications are many.

② The block eccentricity is used as the exciting force, and the exciting force is strong.

③ The sieve beam and the screen box are connected by high-strength bolts without welding.

④ The sieve machine has a simple structure and is convenient and quick to repair.

⑤ Adopting small amplitude, high frequency and large dip angle structure, the machine has high screening efficiency, maximum

processing, long life, low power consumption and low noise.

Round Ultrasonic Sand Vibrating Screening Machine 18.5Kw 3YK1848 With Mn Steel Net 6

Questions & Answers
1. How long is the delivery time of your product?
The delivery time is within 20 working days.

2. What is the payment term?
The payment term is T/T.

3.How long is the product warranty period?
Our warranty period is 1 year, excluding wearing parts.

4.What's the after sale service of your company?
We will provide foundation drawing to the clients for installation. Besides, we can provide guidance service for installation and operation of workers, etc.

5. Can your company provide wearing parts?
We can deliver you the spare parts within 10 working days after your order. If your equipment are not manufactured by our company, please provide us the wearing parts drawing or number.
